NEXUS© UVI MACHINE FILM

  • Takes load containment to the next level
  • Performs under harsh conditions
  • Proven dependability of the Nexus product line
  • UVI additive enables outdoor storage of wrapped loads

FEATURES & BENEFITS

  • Ultraviolet Inhibitor additive extends stretch film integrity during UV exposure
  • Excellent force to load reduces film breaks/tears
  • One side cling eliminates tails/recoil
  • Fewer roll changes = lowest cost per pallet
  • Reduced carbon footprint
Nexus UVI Machine Film Gauge (US) Micron Width (cm) Length (ft) Cases or Rolls/pallet Lbs/Roll
NXUV. 178500 70 17.8 50 6500 40 35.85
NXUV. 178750 70 17.8 75 6500 20 53.69
NXUV. 229500 90 22.9 50 5000 40 35.46
NXUV. 229750 90 22.9 75 5000 20 53.10

Paragon FIlms UVI products are formulated and tested to provide at least six months of protection under most conditions; however, many variables impact the integrity of stretch film in outdoor conditions. PARAGON FILMS DOES NOT GUARANTEE UVI PROTECTION AND SPECIFICALLY DISCLAIMS ALL EXPRESS OR IMPLIED WARRANTIES INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

CONTACT US

1 (800) 274-9727

www.paragonfilms.com
torque

NEXUS® UVI TECHNICAL DATA SHEET

17.8 Micron 22.9 Micron
Thickness ASTM D-4649 Gauge 70(17.8) 90(22.9)
Puncture Force ASTM D-5748 Pounds 6.3 7.3
Tensile Ultimate MD ASTM D-882 PSI 5390 5490
Tensile Ultimate CD ASTM D-882 PSI 5180 5400
Tensile Yield MD ASTM D-882 PSI 1365 1440
Tensile Yield CD ASTM D-882 PSI 1365 1400
Elongation at MD ASTM D-882 % 460 480
Elongation at CD ASTM D-882 % 630 650
Unstretched Cling ASTM D-4649 Grams (g)/in 179 166
All values are represented of typical film performance and are not to be constructed as manufactured and/or sales specifications
